FuseBox - TPNI080 - 3P&N IP65 Metal Isolator Switch - 80A
TPNI080
The FuseBox 80A 3P+N IP65 Metal Isolator Switch provides reliable three-phase isolation in commercial and industrial environments. AC-23A rated with mechanical door interlock, padlockable rotary handle and durable 1.2mm steel enclosure, ensuring safe, compliant and weather-resistant operation.
- 80A 3 Phase + Neutral (3P+N)
- AC-23A utilisation category
- IP65 rated enclosure
- 690V rated operational voltage
- 800V rated insulation voltage
- 8kV impulse withstand
- 1.2mm steel enclosure – RAL7035 finish
- Mechanical door interlock (ON position only)
- Padlockable in OFF position (up to 3 padlocks)
- Removable gland plates top and bottom
- Operating temperature: -25°C to +55°C
| Manufacturer | FuseBox |
| Range | TP&N |
| Standard | IEC BS EN 60947-3 |
| Dimensions | 300mm (H) x 300mm (W) x 150mm (D) |
| Finish | RAL 7035 |
| Material | 1.2mm Steel |
