FuseBox - TPNFS080 - 3P&N IP65 Metal Fused Switch - 80A
TPNFS080
The FuseBox 80A 3P+N IP65 Metal Fused Switch combines reliable three-phase isolation with integrated fuse protection. Featuring 10x38mm gG fuse holders, mechanical door interlock and durable steel enclosure, it ensures safe operation in commercial and industrial installations.
- 80A 3 Phase + Neutral (3P+N)
- AC-23A utilisation category
- IP65 rated enclosure (fuse holder IP20)
- 690V rated operational voltage
- 800V rated insulation voltage
- 8kV impulse withstand
- 1.2mm steel enclosure – RAL7035 finish
- Mechanical door interlock (ON position only)
- Padlockable in OFF position (up to 3 padlocks)
- Removable gland plates top and bottom
- Operating temperature: -25°C to +55°C
- Integrated 10x38mm gG fuse holders
| Manufacturer | FuseBox |
| Range | TP&N |
| Standard | IEC BS EN 60947-3 |
| Dimensions | 500mm (H) x 300mm (W) x 150mm (D) |
| Finish | RAL 7035 |
| Material | 1.2mm Steel |
